HEM CNC Pipeline High-Speed Beveling Machine
Pipe beveling equipment Core Performance
1. Universal Material Compatibility
Designed for thick-walled stainless steel (up to 150mm) and alloy steel pipes, overcoming machining challenges faced by conventional methods.
Processes carbon steel, low-temperature steel, and duplex alloys with zero material degradation.
2. Multi-Bevel Profiling
3. High-Speed Efficiency
Main performance:
Wide adaptability,suitable for groove processing of variousmaterials of pipelines, especially thick walled stainless steel andalloy steel pipes that are difficult to machine by other methods. Thegroove form can be selected within 150mm wall thickness, such asl, U, X, V, double V, double V+U, and inner groove, inner boring, etc.
Comparison of measured processing efficiency data:
|
Workpiece specification (material 304 stainless steel) |
Actual processing time of HEM series CNC groove machin |
Actual processing time of other groove machining of the same type |
|
DN500*28mm |
About30min |
About 1.5 hours |
|
DN600*30mm |
About35min |
About 2 hours |
|
DN750*40mm |
About43min |
About 3 hours |
Equipment parameters/selection:
|
Model |
HEM-400 |
HEM-600 |
HEM-800 |
HEM-1000 |
HEM-1200 |
|
Processing pipe diameter mm |
DN50-400 |
DN100-600 |
DN200-800 |
DN300-1000 |
DN400-1200 |
|
Processing wall thickness mm |
5-80 |
5-110 |
5-110 |
5-110 |
5-110 |
|
Processing pipe length mm |
≥500 |
≥500 |
≥500 |
≥500 |
≥500 |
|
Power head power KW |
4.0 |
7.5 |
11.0 |
11.0 |
11.0 |
|
Axial displacement stroke ofpower head mm |
200 |
300 |
300 |
300 |
300 |
|
Processing method |
X/Y/Z three-axis linkage, Siemens or Mitsubishi CNC system controls high-speed rotation of the cutter head (Z-axis), |
||||
|
Radial fed and retreat control |
servo motor control, radial automatic feed and retreat, servo motor power 400W |
||||
|
Radialfeed and retreattool transmission |
Servo motor+high-precision planetary reducer +worm gear transmission mechanism+screw and nut group |
||||
|
Axial feed and retreat control |
Servo motor control, axial automatic feed and retreat, servo motor power 1500W |
||||
|
xial forwvard andba kwat ,warandbadkward |
Servo motor+high-precision planetary reducer +screw, nut set |
||||
|
Axial empty Ctin speed |
0-400mm/min, infinitely adjustable |
||||
|
Axial load feed speed |
0-5mm/r, infinitely adjustable |
||||
|
Knife disc driveKnife disc drve |
Adopting variable frequency motor, precision gear reducer, and gearbox power head |
||||
|
Knife disc speed |
0-150r/min, infinitely adjustable |
||||
|
Pipe clamping |
Hydraulic left and right self centering clamping pipes |
||||
|
Applicable materials |
Carbon steel, aloy steel, stainless steel, low-temperature steel, heat-resistant steel, duplex stainless steel, nickel based aly, titanium aloy, etc |
||||
|
Groove form |
I type, U type, Xtype, V type, double V type, double V+U type and inner groove, inner boring |
||||
|
Groove angle |
Any angle from0 to 90.is acceptable |
||||
|
Machining tools |
Market standard machine clamp type hard alloy blade, no need for water cooling |
||||
our casey
Lorem ipsum dolor sit amet consectetur adipisicing elit.
Equipment Configuration
HEM CNC Pipeline High-Speed Beveling Machine
HEM pipeline cutting band saw machine host
Belt sawing machine logistics conveying system (mobile trolleymode)
Belt sawing machine logistics conveying system (conveying roller mode)
CNC fixed length system for pipeline cuttinge
Manual screw rod lifting trolley (standard configuration)
Equipment Configuration
Groove host+automatic lifting and conveying roller table+rotary turning system
1. Universal Material Mastery Cnc beveling machine overcoming machining challenges where conventional methods fail.
Processes carbon steel, duplex stainless, nickel alloys, titanium.
2. Multi-Bevel Profiling
3. Ultra-High-Speed Machining
Dual-Station Workflow:
Simultaneous cutting and beveling via integrated band saw and CNC head.
Reduces cycle time by 40% compared to sequential operations.
Adaptive Clamping:
Hydraulic auto-centering jaws (0.5–20-ton force) accommodate ovality in thick-walled pipes.
Smart Controls:
Touchscreen HMI with preloaded programs for ASME B31.3 and ISO 9001 compliant workflows.
Pipe beveling equipment Industry Applications
• Oil & Gas: Fabricate cross-country pipelines with 100% consistency in wall thickness.
• Nuclear Engineering: Machine reactor coolant piping to ASME III Class 1 standards.
• Offshore Platforms: Achieve zero-defect bevels on subsea risers in <4-hour cycles.
Why Choose HEM CNC?
Certified Excellence: CE, ISO 9001, and API 5L compliant.
Future-Ready Design: Modular architecture supports robotic welding integration.
Global Field Proven: Trusted by Fortune 500 firms on projects exceeding 50,000 km of pipeline.
Pipe beveling equipment Engineered for extremes. Trusted for precision.
HEM CNC Pipeline High-Speed Beveling Machine – Redefining Accuracy in Thick-Wall Fabrication.
Contact Us Today to schedule a live demo and discover how HEM CNC transforms pipeline efficiency!
The company specializes in manufacturing electric, pneumatic, hydraulic, CNC, and explosion-proof groove cutting machines. After years of development, Wellnit has won the domestic and international market with excellent quality and perfect service, earning praise and trust from users.
Our address
No.370, Lvgu Avenue, Shuige Industrial Park, Liandu District, Lishui City, Zhejiang Province (No.3 Lisha Road)
Phone Number
+8618058880099
wellnit@foxmail.com
who choose us?
To provide high-quality products, the company has equipped advanced testing equipment and perfect testing methods, established a strictly disciplined quality management team, and achieved full-process quality control covering raw material inspection, production process testing, and product application.
one-stop solution
professional team
high quality
Certifications
Create a comprehensive solution for efficient human theft manag
Export licence
Export licence
Approved Supplier
Export licence
Patent Certificate
Patent Certificate
Zhejiang Wellnit Machinery Manufacturing Co.. Ltd, located in Shuige Industrial Zone, Liandu District, Lishui City. The company specializes in the production of electric, pneumatic, hydraulic, CNC, and explosion-proof groove cutting machinery. After years of development, the company has won the domestic and international markets with excellent quality and perfect service, and is highly praised and trusted by users. The company's top ten series and dozens of products have been exported to more than 60 countries and regions such as Europe, America, the Middle East, and Southeast Asia, and have passed the ISO-9001 international quality system certification.
FAQ
Q: In what situations would you use a fixed high-speed pipe beveling machine?
A: 1. Factory-style, large-scale pipeline prefabrication 2. Handling thick-walled, difficult-to-process pipes 3. High-precision, high-standard welding preparation
Q: What is a fixed pipeline high-speed beveling machine?
A: The fixed pipeline high-speed beveling machine is a CNC machining device that's installed in a workshop or factory. Its main job is to precisely cut and bevel pipe ends before welding. It uses cold milling, so it doesn't change the pipe material due to heat.
Q: How do you choose the right model based on pipe specifications?
A: 1. Pipe diameter range: Check if the equipment can handle the pipe outer diameters you need. 2. Wall thickness capability: Different models can handle different maximum wall thicknesses, with some heavy-duty machines reaching up to 150mm. You also need to consider the type of bevel (whether you need to process V/Y/X/K or other types) and the level of automation (whether you need automatic loading/unloading and other extra features).
Q: How do I apply for a quote for a fixed high-speed pipeline cutting beveling machine?
A: Contact us via email at wellnit@foxmail.com, or reach out through WhatsApp at +86 180 5888 0099-feel free to get in touch anytime. Please specify the type of product you need, quantity per item, strength grade (if any), surface treatment requirements, delivery location, and the required delivery date. Our engineering and sales team will provide technical confirmation and a quote within 24 hours.
Q: How do we make sure the product's quality?
A: Before mass production, we first run tests on pre-production samples; before shipping, we make sure the machine is working properly through a phone video call to complete the final check. Only then do we pack and ship it.
Q: What's the minimum order quantity and delivery time?
A: The minimum order is one standard machine. Whether it's a single sample order or a bulk project order, we can accept and handle it, and all follow the same quality management system. For in-stock products, we ship within 3-5 working days after payment. For large orders, the standard delivery time starts from the confirmation of the order to receiving the prepayment, and it usually takes about 30 days. A detailed production and delivery schedule will be provided when the order is confirmed.
